Top Challenges in Underground Utility Surveying and How to Overcome Them

Underground Utility Surveying | Takhteet Survey

Underground utility mapping is extremely valuable in construction and infrastructure work because it involves ascertaining the position of any utilities like water supply, electricity, telecommunications as well as gaseous supply lines. Underground utility mapping is one way of avoiding such damages because it locates the utilities hence preventing them from being damaged, it also makes projects safer and makes planning easier. Still, in this process, there are numerous headaches which I will say more in detail below. As we make our way through the process of underground utility survey, let’s discover the primary challenges and how to power through them.

1. Faulty or Inaccurate Utility Reports

A primary problem in underground utility surveying is the absence of valid or up-to-date maps of systems and facilities. The incomplete map can be a result of infrastructure changes, and concealed or undocumented repairs within the corridor over time. This leads to delays or surface uncontrollable during excavation.

Solution:

To counter this, more extensive underground utility mapping solutions are required; including GPRS systems, electromagnetic scanners, and GPS. All these tools help offer accurate and current information regardless of the state of the utility. Also, making changes to the records with the utilities after the survey enables correcting information for other projects.

2. Identifying Non-Metallic Utilities

In other cases, utilities like plastic water pipes or fibre optical cables cannot be seen easily. This can have disastrous ends in that the placemarking may be incorrect or some utilities may not be noticed at all.

Solution:

On the matter of intervention and in particular the use of GPR it is evident that advanced GPR is a very useful tool in identifying non-metallic utilities. GPR can transmit electromagnetic signals into the ground and receive reflected signals from changes in subsurface material. GPR can be supported by electromagnetic detection tools, and in combination, will give thorough data that no utilities are missed.

3. Disturbance by Other Factors within the Environment

Some factors affecting the accuracy of a given underground utility survey may include the quality of the soil for the area, moisture on the ground or any presence of metallic objects nearby. For instance, GPR performance may be reduced due to wet soils or interference through the high-density metallic environment.

Solution:

Workers involved in surveying should ensure they survey the location before commencing a survey. When several technologies and techniques are employed in parallel and the outcomes are compared, the impacts of interference from the environment are reduced. For instance, electromagnetic locators should be employed hand in hand with GPR, especially in a more complicated environment.

4. Buried Utilities Overcrowd

The spaces also may well be densely packed in the urban areas meaning that several utilities may run parallel to one another at different levels. It becomes difficult to identify the utilities and to map their positions correctly as well since some utilities may resemble each other.

Solution:

Congestion can be countered through the use of 3D underground utility mapping In 3D mapping, the surveyor aims at developing a visual map of the sub-surface and from the same, determine the depth of each utility and its position. They can also be useful as 3D maps to help project managers in decision-making during construction processes.

5. Safety Risks During Surveys

Underground utility surveys require working in dangerous areas namely in traffic intervention areas, enclosed areas or around high-voltage power lines. All or any of these risks can pose hazards to the welfare of the workers and the equipment as well.

Solution:

To ensure the safety of survey teams survey teams have to adhere to various safety measures and apply equipment with minimal human interaction. For instance, robotic inspection systems can be used where it is extremely hard for an individual to gain access, or where there are dangers prevailing. Further, survey personnel training and personal protective equipment (PPE) should also be enough.

6. Cohort time constraints & financial constraints

Still, time constraints and project budget may pose significant pressure on surveying teams, and lead to poorly conducted, or inadequately planned surveys. This can prove to be expensive if one has to make repairs or replace a utility that was installed when construction was going on.

Solution:

Choosing better quality surveying instruments and personnel may attract a high initial cost but considerably help reduce the costs involved in the course of the project. Uncomplicated technologies such as GPR and GIS mapping make the survey process more efficient and produce results in a shorter time.

Other ways to improve time and resource management include proper project planning and prior coordination with different stakeholders.

7. Regulatory Compliance

The surveying of underground utilities has to meet local codes and practices, and these might differ depending on the region of the world. Failure leads to legal implications and project consequences such as termination or being referred to a court of law.

Solution:

The survey teams should therefore always check on the requirements in the region and liaise with the authorities in the region. It is also easy to coordinate with surveying companies that have some experience in dealing with these regulations.

Conclusion

The surveying of underground utilities is contrary to the conventional expectations of construction and infrastructural development rather a cumbersome task but inevitable. Since it may be faced with challenges like outdated records, environment interferences among others, and charge or utility congestion it can be overcome by the use of tools, techniques and professional knowledge in the field.

Contact us today to know more.
